SK02040.1AXZH-71L/4CUS Nord Gear Gearmotor Motor 0.5 Hp, Ratio 30:1

SK02040.1AXZH-71L/4CUS SK020401AXZH71L4CUS

Nord Gear

(New)

Description

• Product Name: Gearmotor
• Engine Type: CUS
• Motor Speed: 1,720 1 / min
• Motor Speed: 1,720rpm
• Reduction Report: 30.00
• Output Speed: 57,000rpm
• Service Factor: 1.70
• Output Torque M2 (lb-in): 389.00
• Max Torque Output (lb-in): 673.00
• Power (Kw): 0.370
• Power (Hp): 0.500
• Voltage (V): 230/460
• Frequency (Hz): 60
• Service Mode: S1
• Motor Protection Type: IP55
• Insulation Class: F
• Nominal Intensity 1 (Amp): 1.90
• Nominal Intensity 2 (Amp): 0.95
• Cosine 1: 0.69
• Motor Environment Temperature: 40 ° C
• Mounting Position: M1
• Enclosure Type (Reducer): Hollow Shaft, B14 Flange, Footed
• Shaft dimension (mm / in): 20H7
• Event Valve: Vent
• Protective Hood H: Hood
• Position Of The Hollow Shaft Cover: Cover Delivered Unassembled
• Connection Mode: Star
• Terminal Box Position: 4 / II
