SHR-24C Sung-II Machinery Drive Coupling, 8 x 10mm Bore
Country Of Origin: Country Not Available
Product Information
Sold By Unit
SHR24C
| Item | Drive coupling |
| Coupling Type | Servo high gain |
| Material | Aluminum alloy |
| Rated Torque | 3.5 N-m |
| Maximum Torque | 7 N-m |
| Maximum Angular Misalignment | 1.5 degrees |
| Maximum Parallel Misalignment | 0.15mm |
| Maximum RPM | 25000 |
| Attachment Style | Clamp |
| Coupling Size | 24 |
| Bore Diameter | 8mm |
| Bore Diameter 2 | 10mm |
| Outside Diameter | 23.8mm |
| Clamp Screw Fastening Torque | 1.1 N-m |
| Clamp Screw Size | M2.6 |
-
