O8P204 Ifm Electronic Retro-Reflective Sensor Red Light IO-Link
O8P204
O8P-DPKG/IO-Link/0,30M/AS/4P O8PDPKGIOLink030MAS4P
Ifm Electronic
(New In Bag Sealed)
- Particularly Small Housing For Use Where Space Is Restricted
- For The Reliable Position Detection In Feeding And Handling Technology
- Precise Detection Of Very Small, Very Flat, Or Highly Reflective Components
- Easy Setting Of The Range With IO-Link
- Very Long Range
Description
- Function Principle: Retro-Reflective Sensor
- Type Of Light: Red Light
- Communication Interface: IO-Link
- Housing: Rectangular
- Dimensions [mm]: 28.1 x 8.1 x 14.4
- Special Feature: Polarisation Filter
- Operating voltage [V]: 10...30 DC
- Current consumption [mA]: 20; ((24 V))
- Protection Class: III
- Reverse Polarity Protection: yes
- Type Of Light: Red Light
- PNP: 0.3
- Dark-On Mode
- WaveLength [nm]: 633
- Connection: Cable: 0.3 m, PVC, Black, Ø 2.9 mm; 3 x 0.08 mm²
- Connection: Connector 1 x M8
