Ifm IM0053 Inductive Sensor
Country Of Origin:
| Output function | normally open |
|---|---|
| Sensing range [mm] | 35 |
| Housing | rectangular |
| Dimensions [mm] | 40 x 40 x 66 |
| System | gold-plated contacts; Increased sensing range |
|---|
| Operating voltage [V] | 20...250 AC/DC |
|---|---|
| Protection class | I |
| Reverse polarity protection | no |
| Output function | normally open |
|---|---|
| Max. voltage drop switching output DC [V] | 6 |
| Max. voltage drop switching output AC [V] | 6.5 |
| Minimum load current [mA] | 1.9 |
| Max. leakage current [mA] | 2.5 (250 V AC) / 1.3 (130 V AC) / 0.8 (24 V DC) |
| Permanent current rating of switching output AC [mA] | 250; (350 (...50 °C)) |
| Permanent current rating of switching output DC [mA] | 100 |
| Short-time current rating of switching output [mA] | 2200; (20 ms / 0,5 Hz) |
| Switching frequency AC [Hz] | 20 |
| Switching frequency DC [Hz] | 50 |
| Short-circuit proof | no |
| Overload protection | no |
| Sensing range [mm] | 35 |
|---|---|
| Operating distance [mm] | 0...28.3 |
| Increased sensing range | yes |
| Correction factor | steel: 1 / stainless steel: 0.8 / brass: 0.4 / aluminum: 0.4 / copper: 0.3 |
|---|---|
| Hysteresis [% of Sr] | 3...15 |
| Ambient temperature [°C] | -25...70 |
|---|---|
| Protection | IP 67 |
| EMC |
|
||||
|---|---|---|---|---|---|
| MTTF [years] | 600 |
| Weight [g] | 160.5 |
|---|---|
| Housing | rectangular |
| Mounting | non-flush mountable |
| Dimensions [mm] | 40 x 40 x 66 |
| Material | housing: PPE; sensing face: PPE orange; end cap: PPS; clamp: PPS black; screw: steel galvanized |
| Display |
|
|---|
| Required protection | miniature fuse to IEC60127-2 sheet 1; ≤ 2 A; fast acting |
|---|
| Remarks |
|
||
|---|---|---|---|
| Pack quantity | 1 pcs. |
| Connector: 1 x M12; coding: C; Locking: brass, white bronze coated; Contacts: gold-plated |
