Century Spring 71808S 1.50 Inch Compression Spring, Sold By Unit

SKU SPG-0188-E
Original price $18.28 USD - Original price $18.28 USD
Original price
$18.28 USD
$18.28 USD - $18.28 USD
Current price $18.28 USD
Availability:
Only 4 left!

Delivery Option

Ups Express next day air or standard shipping is available at the checkout !

Request a quote

Industrial Automation Parts is Not Authorized Distributor of this product. Manufacturer's Warranty & Support DO NOT apply. Our IAP warranty of 3 month is applicable.

Description:

  • Part Type: Standard compression spring
  • Material: 302/304 Stainless Steel
  • Finish: None
  • Outside Diameter: 0.6 in
  • Inside Diameter: 0.438 in
  • Wire Diameter: 0.082 in
  • Total Coils: 8.9
  • Free Length: 1.5 in
  • Solid Length: 0.729 in
  • Rate: 59 lbs/in (spring rate)
  • Suggested Max Deflection: 0.482 in
  • Suggested Max Load: 29 lbf
  • Sold By Unit
