AL2401 Ifm Electronic IO-Link CompactLine Module 8 x 2 DI

SKU PLC-1163-U
Sold out
Original price $190.00 USD - Original price $190.00 USD
Original price
$190.00 USD
$190.00 USD - $190.00 USD
Current price $190.00 USD
Availability:
Out of stock

Delivery Option

Ups Express next day air or standard shipping is available at the checkout !

Request a quote
by Ifm

Industrial Automation Parts is only an authorized distributor for DeLock and is not authorized for any other manufacturers. Manufacturer's warranty and support do not apply. Our IAP warranty of three months is applicable.

Condition :

AL2401

Ifm Electronic

IO-Link CompactLine Module 8 x 2 DI

(New In Box)

Description

Electrical Data

  • Operating Voltage [V]: 18...30 DC; ("Supply Class 2" To cULus)
  • Current Consumption [mA]: < 50

Sensor Supply US

  • Current Rating Per Port [A]: 0.1

Inputs

  • Number Of Digital Inputs: 16; (8 x 2)
  • Input Circuit Of Digital Inputs: PNP
  • Sensor Supply Of The Inputs: IO-Link
  • Input Current Limitation [mA]: 15
  • Input Current High [mA]: 6...10
  • Input Current Low [mA]: 0...2
  • Min. Switching Level High Signal [V]: 11
  • Digital Inputs Protected Against Short Circuits: yes

Interfaces

  • Communication Interface: IO-Link
  • Supported DeviceIDs: Type Of Operation, DeviceID; Default: 555

Mechanical Data

  • Weight [g]: 382.5
  • Materials: PA; Socket: Brass Nickel-Plated; O-Ring: FKM
  • Sealing material: FKM

Electrical Connection - IO-Link

  • Connector: M12
