Murrelektronik 7000-12481-0000000 MOSA Connector Male M12 4-Pole

SKU FAS-0313-E
Original price $7.65 USD - Original price $7.65 USD
Original price
$7.65 USD
$7.65 USD - $7.65 USD
Current price $7.65 USD
Availability:
22 in stock, ready to be shipped

Delivery Option

Ups Express next day air or standard shipping is available at the checkout !

Specifications
Request a quote

Industrial Automation Parts is Not Authorized Distributor of this product. Manufacturer's Warranty & Support DO NOT apply. Our IAP warranty of 3 month is applicable.

Product Information

  • 7000124810000000
  • Operating Voltage Max. 32 V AC/DC
  • Rated Surge Voltage 0.8 kV
  • Operating Current Per Contact Max. 4 A
  • Material Group IEC 60664-1, category III
  • Connection Cross-Section 0.25...0.5 mm² (conductor diameter min. 0.1 mm)
  • Sealing Range (cable Ø) 4...5.1 mm
  • Wire Isolation PVC, PP, TPE
  • Outer Wire Ø 1.2...1.6 mm
  • Locking Of Ports Screw Thread (M12×1 mm) Recommended Torque 0.6 Nm, Self-Securing
  • Protection IP67 Mounted And Tightened
  • Reconnection (cable) 10
