160273 YSR-25-40-C Festo Pneumatic Shock Absorber Size 25 Stroke 40 mm

160273 YSR-25-40-C YSR2540C

Festo

Pneumatic Shock Absorber

Description

• Size: 25
• Stroke: 40 mm
• Cushioning: Self-Adjusting
• Mounting position: Any
• Symbol: 00991497
• Max. impact velocity: 3 m/s
• Reset Time At Room Temperature: 0.4 s
• Reset Time At Min. Ambient Temperature: 1 s
• Mode Of Operation: Single-Acting, Pushing
• Corrosion Resistance Class (CRC): 2 - Moderate Corrosion Stress
• Ambient Temperature: -10 °C ... 80 °C
• Cushioning Length: 40 mm
• Max. Stop Force: 4000 N
• Type Of Mounting: With Lock Nut
• Note On Materials: RoHS-Compliant
• Seals Material: NBR
• Housing Material: Steel, Galvanized
• Piston Rod Material: High-Alloy Steel
• Product Weight: 600 g
