Festo 150857 SME-8-S-LED-24 Proximity Sensor, M8, 3-Pin, 24V DC, PNP
Product Information
SME8SLED24
- Design: For T-Slot
- Conforms To Standard: En 60947-5-2
- Symbol: 00991148
- Certification: RCM Compliance Mark
- Ce Marking (See Declaration Of Conformity): As Per EU EMC Directive
- Note On Materials: Free Of Copper And PTFE
- Measuring Principle: Magnetic Reed
- Ambient Temperature: -40 °C ... 70 °C
- Switching Output: Contact-Based, Bipolar
- Switching Element Function: N/O Contact
- Reproducibility Of Switching Value: +/- 0.1 mm
- On-Time: 0.5 ms
- Switch-off Time: 0.03 ms
- Max. Output Current: 500 mA
- Min. Switching Capacity Ac: 10 VA
- Max. Switching Capacity DC: 10 W
- Short-circuit Protection: No
- Overload Protection: Not Available
- Operating Voltage Range AC: 12 V ... 30 V
- DC Operating Voltage Range: 12 V ... 30 V
- Reverse Polarity Protection: No
- Electrical Connection: 3-Pin
- Cable With Plug: M8x1
- Connection Outlet Orientation: Longitudinal
- Material Of Pin Contacts: Brass; Nickel-Plated
- Cable Length: 0.3 M
- Material Of Cable Sheath: TPE-U (PUR)
- Type Of Mounting: Clamped In T Slot; Can Be Inserted In Slot Lengthwise
- Tightening Torque: 0.2 Nm
- Product Weight: 8 g
- Housing Material: Epoxy Resin, PC, PET, High-Alloy Stainless Steel
- Switching Status Indication: LED Yellow
- Ambient Temperature With Flexible Cable Installation: -5 °C ... 70 °C
- Degree Of Protection: IP67
- Insulation Voltage: 50 V
- Surge Resistance: 0.8 VK
- Contamination Level: 3
