11234 Century Spring Regular Compression, 20.5 Coils, Length 4.13" x 0.53", New

11234 Century Spring Regular Compression, 20.5 Coils, 4.13" x 0.53"

Name: 11234 Century Spring Regular Compression, 20.5 Coils, 4.13" x 0.53"
Brand: CENTURY SPRING
SKU: SPG-0227-E
Price: 3.45 USD
Availability: InStock

SKU SPG-0227-E

$3.45 USD - $3.45 USD

$3.45 USD

$3.45 USD - $3.45 USD

$3.45 USD

Availability:

9 in stock, ready to be shipped

Pre Order

Delivery Option

Ups Express next day air or standard shipping is available at the checkout !

Specifications

by CENTURY SPRING

Industrial Automation Parts is Not Authorized Distributor of this product. Manufacturer's Warranty & Support DO NOT apply. Our IAP warranty of 3 month is applicable.

Description

11234

Century Spring

Sold By Unit, New

Regular Compression Spring In Spring Steel With 20.5 Total Coils And Closed & Ground Ends.
This Spring Features An O.D. Of 0.531 Inch, An I.D. Of 0.437 Inch, And A Spring Rate Of 3.3 Pound Force Per Inch.

Description

Ends: Closed & Ground
Finish: Zinc
Free Length: 4.13 in
Inside Diameter: 0.437 in
Material: Spring Steel
Outside Diameter: 0.531 in
Part Type: Standard
Rate: 3.3 lbs/in
Solid Length: 0.96 in
Suggested Max Deflection: 2.3 in
Suggested Max Load: 7.6 lbs
Total Coils: 20.5000
Wire Diameter: 0.047 in
