10405 Century Spring Regular Compression Spring, 5.25 Coils, 1.94" L

Name: 10405 Century Spring Regular Compression Spring, 5.25 Coils, 1.94" L
Availability: InStock

SKU SPG-0327-E

$12.30 USD - $12.30 USD

$12.30 USD

$12.30 USD - $12.30 USD

$12.30 USD

Availability:

Only 4 left!

Quantity

Delivery Option

Ups Express next day air or standard shipping is available at the checkout !

by CENTURY SPRING

Industrial Automation Parts is Not Authorized Distributor of this product. Manufacturer's Warranty & Support DO NOT apply. Our IAP warranty of 3 month is applicable.

Condition :

Description

Product Information

Sold By Unit

Regular Compression Spring In Spring Steel With 5.25 Total Coils And Closed & Ground Ends.

This Spring Features An O.D. Of 1.5 Inch, An I.D. Of 1.274 Inch, And A Spring Rate Of 27 Pound Force Per Inch.

Ends: Closed & Ground
Free Length: 1.94"
Inside Diameter: 1.274"
Material: Spring Steel
Outside Diameter: 1.5"
Part Type: Standard
Rate: 27 lbs/in
Solid Length: 0.59 in
Suggested Max Deflection: 1.1"
Suggested Max Load: 31 lbs
Total Coils: 5.2500
Wire Diameter: 0.113 in

10405 Century Spring Regular Compression Spring, 5.25 Coils, 1.94" L
