Navilock 62447 Nl-6004P Md6 Serial Gps Receiver U-Blox 6 5 M
Country Of Origin: Taiwan
• Chipset: u-blox NEO-6P
• PPP (Precision Point Positioning)
• Frequency: GPS: L1, 1575.4200 MHz
• Accepts the signals of up to 50 satellites at the same time
• Intergrated anti-jamming technology
• Supports AssistNow online / offline, SBAS (WAAS, EGNOS, QZSS and MSAS)
• Supports NMEA 0183 protocols: GGA, GSA, GSV, RMC, VTG, GLL
• Auto Baud Rate up to 115200 bps
• Update rate: up to 1 Hz
• Sensibility max. -160 dBm
• Protection class: IPX7
• Operating temperature: -20 °C ~ 60 °C
• Power supply: 5 V DC
• Current consumption: max. 60 mA
• Cold start in ca. 38 seconds
• Hot start in ca. 1 second
• Positioning accuracy:
GPS: 2.5 m
SBAS: 2.0 m
SBAS + PPP: < 1 m (2D, R50)
SBAS + PPP: < 2 m (3D, R50)
Demonstrated under following conditions: 24 hours, stationary, first 600 seconds of
data discarded, HDOP < 1.5 during measurement period, strong signals. Continuous
availability of valid SBAS correction data during full test period.
• Cable length: ca. 5 m
• Dimensions (Ø x H without screw thread): ca. 62 mm x 21 mm
Microsoft Sensor and Location Platform (Website)
• Profit from Windows applications (e.g. weather, maps, etc)
• Supporting the GNSS location platform API (32 bit)
-
