BQ1B020 Siemens, Low Voltage Molded Case Circuit Breaker, 20A, 120V AC
Country Of Origin: Mexico
BQ1B020
Siemens
Type BQ Low Voltage Molded Case Circuit Breaker, 120 VAC, 20 A, 10 kA Interrupt, 1 Pole, Thermal Magnetic Trip
Description
- Type: Type BQ Low Voltage
- Series: BQ
- Voltage Rating: 120 VAC
- Amperage Rating: 20 A
- Frequency Rating: 60 Hz
- Interrupt Rating: 10 KA
- Frame: BQ/125 A
- Trip Type: Thermal Magnetic
- Number Of Poles: 1
- Phase: 1
- Actuator Type: Toggle
- Connection Type: Bolt-On/Lug-In/Lug-Out
- Wire Size: 14 To 10 AWG, 12 To 10 AWG
- Mounting Type: Panel
- Temperature Rating: 40 Deg C
- Dimensions: 12.9 in L X 4.6 in W X 3.8 in H
- Color: Black
-
