531879 Festo MS6N-LFM-1/2-A-U-V Micro Filter

Product Information

MS6NLFM12AUV

• SeriesMS
• Size6
• Structural designFiber filter
• Grade of filtration0.01 µm
• Condensate drainFully automatic
• Symbol00991520
• Operating pressure2 bar ... 12 bar
• Operating mediumCompressed air as per ISO 8573-1:2010 [6:8:4] Inert gas
• Air quality class at the outputCompressed air as per ISO 8573-1:2010 [1:7:2]
• Max. standard flow rate for air quality class900 l/min
• Min. standard flow rate for air quality class135 l/min
• Filter efficiency99.9999 %
• Max. condensate volume38 ml
• Bowl guardIntegrated as metal bowl guard
• Corrosion resistance class (CRC)2 - Moderate corrosion stress
• LABS (PWIS) conformityVDMA24364-B1/B2-L
• For use in the food industrySee supplementary material information
• Temperature of medium-10 °C ... 60 °C
• Ambient temperature-10 °C ... 60 °C
• Storage temperature-10 °C ... 60 °C
• Residual oil content0.01 mg/m³
• Type of mountingLine installation With accessories Optionally:
• Mounting positionVertical +/- 5°
• Pneumatic connection 11/2 NPT
• Pneumatic connection 21/2 NPT
• Housing materialDie-cast aluminum
• Compressed air filter materialBorosilicate fiber
• Material of bowlWrought aluminum alloy
• Seals materialNBR
• Note on materialsRoHS-compliant
• Product weight820 g
