Festo LFR-1-D-MAXI-NPT 173812 Filter Regulator Maxi Size D-Series

Product Information

Filter Regulator With Metal Bowl Guard, Pressure Gauge, And Manual Condensate Drain.

• LFR1DMAXINPT
• Size: Maxi
• Series: D
• Assembly Position: Vertical
• Grade Of Filtration: 40 mm
• Condensate Drain: Manual Rotary
• Max. Condensate Volume: 80 cm3
• Bowl Guard: Metal Bowl Guard
• Operating Pressure: 1 ... 16 bar
• Max. Pressure Hysteresis: 0.4 bar
• Standard Nominal Flow Rate: 10,000 L/min
• Operating Medium: Compressed Air To ISO 8573-1:2010 [-:9:-] Inert Gases
• Note On Operating And Pilot Medium: Lubricated Operation Possible (Subsequently Required For Further Operation)
• Corrosion Resistance Classification CRC: 2 - Moderate Corrosion Stress
• Storage Temperature: -10 ... 60 °C
• Air Purity Class At Output: Compressed Air In Accordance With ISO8573-1:2010 [7:8:4] Inert Gases
• Medium Temperature: -10 ... 60 °C
• Ambient Temperature: -10 ... 60 °C
• Product Weight: 1,470 G
• Mounting Type: With Accessories
• Pneumatic Connection, Port 1: 1 NPT
• Pneumatic Connection, Port 2: 1 NPT
• Materials Note: Conforms To Rohs
• Material Housing: Zinc Die-Casting
• Material Bowl: PC
