Ifm IG6210 Inductive Sensor
Country Of Origin:
| Electrical design | PNP |
|---|---|
| Sensing range [mm] | 8 |
| Housing | Threaded type |
| Dimensions [mm] | M18 x 1 / L = 54 |
| Operating voltage [V] | 10...36 DC |
|---|---|
| Current consumption [mA] | < 15 |
| Protection class | II |
| Reverse polarity protection | yes |
| Electrical design | PNP |
|---|---|
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 250 |
| Switching frequency DC [Hz] | 500 |
| Short-circuit protection | yes |
| Type of short-circuit protection | yes (non-latching) |
| Overload protection | yes |
| Sensing range [mm] | 8 |
|---|---|
| Real sensing range Sr [mm] | 6.48 |
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 |
|---|---|
| Hysteresis [%] | 1...20 |
| Ambient temperature [°C] | -40...70 |
|---|---|
| Protection | IP 69K |
| EMC |
|
||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Shock resistance |
|
| Weight [g] | 82.5 |
|---|---|
| Housing | Threaded type |
| Mounting | flush mountable |
| Dimensions [mm] | M18 x 1 / L = 54 |
| Thread designation | M18 x 1 |
| Material | housing: brass white bronze coated; sensing face: PBT; end cap: TPU (urethane) |
| Tightening torque [Nm] | 25 |
| Display |
|
|---|
| Items supplied |
|
|---|
| Notes | customer-specific |
|---|---|
| Pack quantity | 1 pcs. |
| Cable: 0.125 m, PUR, Ø 5.4 mm; 3 x 0.5 mm² | |
| Connector: 1 x DEUTSCH connector ((DT04-3P-CE02)) |
